Cross-Section

The Anatomy of Strength

Every component engineered for load, longevity, and rapid deployment. Here's what's inside a single deck panel.

Scroll to explore

Cross-Section View — Single Panel

6 ft 6 in (78 in)
Boards Kiln-dried SYP laminations set on edge
Steel Channel Structural perimeter frame
Stressing Rod High-tensile threaded steel
Hex Nuts Lock rod tension in place
Bearing Plate Distributes compression across the deck

Construction

Built Layer by Layer

From raw lumber to road-ready bridge in eight precision steps.

Plan View — Two-Panel Bridge Assembly

PANEL 1 PANEL 2 13 ft 30 ft
01

The Timber Deck

Kiln-dried Southern Yellow Pine boards are set on edge and packed tightly side by side, forming the structural deck slab.
